In a fire, every second counts. FDS offer a wide range of fire-resistant steel doors that have been expertly crafted to endure hours of intense heat. This can provide vital time for employee evacuation, as well as aiding firefighters to control the blaze.
At FDS, we don’t compromise on safety—so if you want to upgrade your fire protection, don’t hesitate to enquire about our fire resistance steel doors.
| Description | Fire-rated steel door. |
| Applications | Commercial, industrial, public. |
| Security Level | High. Certified for fire resistance for 2 hours, according to Exova Warringtonfire Report Number 312853. |
| Fitting | Internal face, external face, reveal fit. |
| Slat | Single-skinned curved steel. Thickness of 0.9mm. |
| Casing | Galvanised steel casing & end plates as standard. Larger shutters incorporate barrel support frame where required. Reveal fix installations are supplied with a fascia as standard. |
| Guides | Galvanised steel. |
| Bottom Rail | T’ shaped bottom rail. |
| Slat Face | 76mm |
| Weight | 12.5kg/m² |
| Max Width | 7000mm to 12000mm (dependent on fire rating, motor and barrel support – larger sizes may be available on request) |
| Max Area | 15m² to 50m² (dependent on fire rating, motor and barrel support – larger sizes may be available on request) |
| Guide Width | 65mm (wind guide option available), 75mm, 100mm |
| U-Value | N/A |
| Curtain | Galvanised as standard. Option to powder coat any RAL / BS colour or to choose from a range of plastisol finishes. |
| Casing | Galvanised as standard. Option to powder coat any RAL / BS colour (surcharge applies). |
| Guides | Galvanised as standard. Option to powder coat any RAL / BS colour (surcharge applies). |
| Electric | Tubular Motor = NRG Econom tubular motor with internal rocker or external key switch as standard & safety brake as appropriate to comply with legislation. Manual override facility & crank handle as required (surcharge applies). Inline Motor = Single phase inline chain driven motor (three phase option available) with push button control, chain override, fusible link and solenoid release as standard. |
| All fire shutters can be connected to a fire alarm via an interface panel. | |
| Guide Height (up to mm) | Plate Size (mm) |
| 2500 | 305 |
| 4000 | 355 |
| 6000 | 400 |
Get expert advice from our team of fire door installers and fire door joiners to ensure fire door legislations are met.
Simply complete the form and a member of our team will be in touch within 24 hours.
Here are a couple of questions we get asked regularly.
When you buy an industrial door system, your company becomes responsible for maintaining it and ensuring it is safe to use. So you need to know that the doors you choose meet relevant UK health and safety standards.
When you purchase doors from FDS, you can rest assured: all of our doors are fully compliant with UK law.
Here at FDS we have public liability insurance in place and are happy to provide the associated documentation. Just ask if you’d like to see it.
This insurance covers your company in the unlikely event that something goes wrong during fire door installation. And it’s something every industrial door company should have.
Yes, they do. Any fire door system from FDS comes with a 1 year warranty.
Absolutely. We know how important it is to your business to keep industrial door systems operating safely and efficiently.
We offer an aftercare service package, providing ongoing support and ensuring that health and safety standards are maintained. We also provide a 24/7 emergency door repair service.
Our office is open 24 hours a day, from Monday to Saturday. Whatever you need, the friendly and knowledgeable FDS team are available to offer advice and support.
And if you have a repair emergency, you can call our 24 hour emergency hotline. This service is available 24/7, every single day of the year. In the case of a breakdown, our round the clock service and speedy emergency response ensure downtime is kept to a minimum.
Find our contact details here.
FDS offers a comprehensive service package to ensure your fire rated hardware remains compliant with fire safety standards, as well as maintaining efficiency over their lifespan.
